Brandschutzpaneele Trimoterm

Product description

The Trimoterm fireproof façade system is a high-quality, versatile and environmentally friendly construction product for use where the highest demands of fire resistance, thermal insulation, water and airtightness are required. It offers the perfect combination of functionality and durability, whilst also delivering true architectural expression. Available with a complete system of matching components and meeting local-specific requirements and regulations, Trimoterm is suitable for a wide range of insulated external façade, backing-wall for final cladding and roof cladding, internal walls, fire internal walls, food and hygiene walls and ceilings.

TOTAL WALL SOLUTION
1.Wide range of profile types and applications
2.Range of ancillary interface items, bespoke solutions, pre-fabricated corners, aluminum extrusions and feature details
3.Versatile stand-alone system or carrier structural wall for final cladding

MAXIMUM SAFETY
1.Class A1 non-combustible mineral wool insulation core
2.Exceptional fire resistance up to class EI 240 minutes of integrity and insulation
3. Advanced thermal and sound insulation and structural spanning performance
4.Extremely high level of airtightness and watertightness

THE TECHNICAL CHARACTERISTIC PRESENTED IN DGNB NAVIGATOR: Trimoterm Power T façade panel: Panel thickness (mm) 240 mm Panel lenght:4000 mm Mass (kg/m²): 30,60 EI Fire resistance – FTV: EI240 Thermal transmittance (W/m² K): 0,16 Airborne sound insulation (C;Ctr) (dB): 30 (-1;-3) Combustibility of insulant core: Mineral wool non-combustible Class A1 Suitable for corrosion environment: C2, C3, C4 Water permeability: Class A (1200Pa)
