Parador GmbH Parador GmbH

Designboden Vinyl mit HDF-Trägerplatte

Registration Code: P31S8X

Quality phase Sentinel Holding Institut GmbH
ENV1.2 Version 2018 Risiken für die lokale Umwelt
(7 Bodenbeläge (Elastische Bodenbeläge) )
QS 4
ENV1.2 Version 2023 Risiken für die lokale Umwelt
(47c Bodenbeläge in der Innenanwendung (aus Holzwerkstoffen))
QS 3
ENV1.2 Version 2023 Risiken für die lokale Umwelt
(47c Holzwerkstoffe bei Bodenbelägen)
QS 3
Holz und Holzwerkstoffe (u. nachw. Rohstoffe)
Kunststoffe

Product description

Parador vinyl flooring is a real high performer - German Manufactured Quality. As a very popular floor covering, Parador vinyl is low-emission and antibacterial and, thanks to its robustness and long life cycle, contributes to the careful use of our natural resources. All Parador vinyl floors are regularly tested for their safety with very good results and found to be good.

Their special surface finish has a repellent effect against dirt and bacteria. As a design floor, our vinyl flooring is very quiet and easy to clean, making it perfect for households with children, allergy sufferers and flatmates with four paws.

Vinyl with HDF core board is the perfect solution for the design of all living spaces where slight unevenness needs to be levelled out. The integrated cork footfall sound insulation ensures quiet room acoustics and a high level of walking comfort. Vinyl with HDF core board is robust and easy to clean and can be laid easily thanks to the click system.

Instructions for use

Vinyl design floors with an HDF core board are suitable for private and commercial indoor use. They are either laid floating on screed or other existing subfloors in conjunction with a suitable underlay.

Die Grundsätze ordnungsgemäßer Verlegung können der den Paketen beiliegenden Verlege-Anleitung bzw. dem 'Ratgeber Designboden Vinyl und Modular ONE' entnommen werden (siehe https://parador.de/services/downloads/designboden).

Reference to the DGNB system

ENV1.1 Building life cycle assessment
ENV1.1 Building life cycle assessment
Photochemical ozone creation potential (POCP)
1) Production stage
4.06E-02
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Module not declared
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
7.19E-03
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-3.48E-03
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg NMVOC-Equivalent
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Total use of non-renewable primary energy (PENRT)
1) Production stage
1.96E+02 MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Module not declared MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
1.08E+01 MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-5.93E+01 MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Total use of renewable primary energy (PERT)
1) Production stage
1.49E+02 MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Module not declared MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
2.73E+00 MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-1.62E+01 MJ
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
General life cycle assessment data
Building material class
Bfl - s1
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Reference Unit
1m²
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
If necessary, conversion of the reference unit
not required
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
End of life cycle
In the event of selective dismantling, the product can be recycled or reused without any problems even after the end of the utilisation phase. Residues and waste from vinyl flooring with HDF core boards must be recycled in accordance with AVV 17 02 03. Disposal must be organised under the following AVV code: AVV code 17 02 03. If repeated use as flooring is no longer possible, the product can be sent for thermal utilisation to generate heat and electricity. Open incineration or incineration in a fireplace is not possible, as the incineration of plastics leads to harmful emissions. Incineration should therefore take place in a plant with connected flue gas cleaning, such as a waste incineration plant.
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Useful life
20 years
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Global Warming Potential (GWP)
1) Production stage
2.85E+00
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Module not declared
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
1.13E+01
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-3.49E+00
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg CO2-Equivalent
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Eutrophication (EP)
1) Production stage
4.38E-05; 1.51E-02; 1.5E-01
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Module not declared
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
1.64E-06; 2.76E-03; 3.22E-02
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-4.77E-06; -1.24E-03; -1.33E-02
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg P-Eq. [EP-freshwater]; kg N-Eq. [EP-marine]; mol N-Eq. [EP-terrestrial]
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Acidification potential (AP)
1) Production stage
5.7E-02
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Module not declared
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
6.2E-03
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-4.57E-03
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Unit
mol H+- Equivalent
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Ozone Depletion Potential (ODP)
1) Production stage
1.93E-10
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Module not declared
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
4.67E-12
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-2.34E-11
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg CFC11-Equivalent
Source
EPD-PAR-20230152-IBC1-EN
Quality
[Externally audited specific manufacturer information]
ENV2.2 Potable water demand and waste water volume
ENV2.2 Potable water demand and waste water volume
Installation-specific connected load
Flow rate (for sanitary fittings)
not relevant l/sec
Source
-
Quality
[Unaudited manufacturer specification]
Average flushing volume (of the sanitary equipment)
not relevant l/flush
Source
-
Quality
[Unaudited manufacturer specification]
ECO1.1 Life cycle costs
ECO1.1 Life cycle costs
Actual useful life
20 years
Source
BBRS table
Quality
[Externally audited industry specification]
PRO1.4 Ensuring sustainability aspects in tendering and contracting
PRO1.4 Ensuring sustainability aspects in tendering and contracting
Tender textes
Suitable tender texts are currently only available in German. You can find them in our German download area under the heading "Ausschreibungstexte“.
Source
Manufacturer
Quality
[Unaudited manufacturer specification]
PRO2.5 Preparation of sustainable use
PRO2.5 Preparation of sustainable use
Maintenance, inspection, operating and care instructions
Information on cleaning and care can be found in the product guide on pages 24 and 25. This can be found at „https://parador.de/en/services/downloads/design-flooring“ under „Guides“
Source
Manufacturer
Quality
[Unaudited manufacturer specification]
SOC1.2 Indoor air quality
SOC1.2 Indoor air quality
Indoor hygiene - volatile organic compounds VOCs
Formaldehyde concentration
< 10 µg/m³
Source
A+ émissions dans l'air intérieur
Quality
[Externally audited specific manufacturer information]
Other emission tests / labels
A+ émissions dans l'air intérieur
Source
Test certificates
Quality
[Externally audited industry specification]
TVOC value
≤ 300 µg/m³
Source
AgBB
Quality
[Externally audited specific manufacturer information]
Approval test according to AgBB scheme is available
Source
AgBB
Quality
[Externally audited specific manufacturer information]
SOC1.3 Acoustic comfort
SOC1.3 Acoustic comfort
Rated building sound insulation value R`w
not relevant dB
Source
-
Quality
[Unaudited manufacturer specification]
SOC1.4 Visual comfort
SOC1.4 Visual comfort
Visual contact with the outside
Class of the sun/glare protection with regard to visual contact to the outside
Source
-
Quality
[Unaudited manufacturer specification]
Colour rendering
Color rendering index Ra of artificial lighting
not relevant
Source
-
Quality
[Unaudited manufacturer specification]
TEC1.3 Quality of the building envelope
TEC1.3 Quality of the building envelope
Class of air permeability (joint permeability)
not relevant
Source
-
Quality
[Unaudited manufacturer specification]
Heat transfer coefficient U
14.71 W/(m²K)
Source
TDS (according to EN ISO 10456)
Quality
[Unaudited manufacturer specification]

Documents

Downloads

Technisches Merkblatt

pdf
Sentinel Holding Institut GmbH

EPD

pdf
Sentinel Holding Institut GmbH

Zertifikat

pdf
Sentinel Holding Institut GmbH

Technisches Datenblatt Designboden Vinyl selected

pdf
Sentinel Holding Institut GmbH

SHI-Produktpass Designboden Vinyl mit HDF-Trägerplatte

pdf
Sentinel Holding Institut GmbH

Technisches Merkblatt

pdf
Sentinel Holding Institut GmbH

Technisches Merkblatt

pdf
Sentinel Holding Institut GmbH

Contact the manufacturer

Parador GmbH

Parador GmbH

Parador GmbH

Millenkamp 7-8
48653 Coesfeld

Related products from this manufacturer

#VH9VFT

Modular ONE Hydron

Parador GmbH
Modular ONE Hydron ist der wasserfeste, leistungsfähige und fortschrittliche Mehrschichtboden für besondere Anforderungen des Alltags. Die wasserfeste Trägerplatte und der wasserfeste Akustikgegenzug geben diesem Boden den besonders leisen und…
Read more
#45KB4Z

Designboden Vinyl zum Verkleben (Dryback)

Parador GmbH
Produktlinie Basic 2.0 Die Produktlinie Parador Vinyl Basic bietet eine große Auswahl an stilsicheren Vinylböden mit einem erstklassigen Preis-Leistungs-Verhältnis, die durch Qualität und Optik genauso überzeugen wie durch ihre Vielseitigkeit und…
Read more
#IE2THN

Parkett Trendtime

Parador GmbH
Parador Mehrschichtparkettböden sind Holzfußböden mit einer Edelholz-Deckschicht. Für die Produktion unserer Parkettböden verwenden wir nur Hölzer aus nachhaltiger Forstwirtschaft, setzen auf Materialbezug aus Europa und verzichten komplett auf…
Read more
Contact

DGNB GmbH
Tübinger Straße 43
70178 Stuttgart
Germany

Phone: +49 711 72 23 22 - 0
Fax: +49 711 72 23 22 - 99
navigator@dgnb.de

Legal
  • Contact
  • Imprint
  • Data protection
  • General terms and conditions
www.dgnb-akademie.de www.dgnb.de www.dgnb-system.de
Nutzung eines veralteten Browsers

Um Ihre Internet-Erfahrung sicherer und so angenehm wie möglich zu gestalten, sollten Sie Ihren Browser hier auf eine neue Version updaten. Das Update ist kostenlos. Wenn Sie diesen PC auf der Arbeit verwenden, sollten Sie Ihren IT-Administrator kontaktieren. Bitte beachten Sie, dass aufgrund des veralteten Browsers diese Webseite unter Umständen nicht korrekt dargestellt wird.
