Tremco CPG Germany GmbH

Flowshield Acoustics

Registration Code: J74K9P

Bauchemische Produkte

Product description

A self-smoothing, flexible, acoustic
insulating, polyurethane coating
system with a matte, UV-stable finish.

Instructions for use

Acoustic insulating, UV-stable, low VOC flooring system for commercial, office and public spaces subject to foot traffic.

Reference to the DGNB system

ENV1.1 Building life cycle assessment
ENV1.1 Building life cycle assessment
Photochemical ozone creation potential (POCP)
1) Production stage
6.92E-3
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
2) Use stage
ND
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
3) End of life stage
1.62E-3
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
4) Benefits and loads beyond the system boundries
-9.87E-4
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Total use of non-renewable primary energy (PENRT)
1) Production stage
2.95E+1 MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
2) Use stage
ND MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
3) End of life stage
5.87E-1 MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
4) Benefits and loads beyond the system boundries
-1.61E+1 MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Total use of renewable primary energy (PERT)
1) Production stage
3.65E+1 MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
2) Use stage
ND MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
3) End of life stage
8.23E-2 MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
4) Benefits and loads beyond the system boundries
-3.52E+0 MJ
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
General life cycle assessment data
Building material class
Bfl-s1
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Reference Unit
kg
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
If necessary, conversion of the reference unit
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
End of life cycle
landfill, incineration
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Useful life
8 years as according to FERFA guidance on Synthethic Resin Flooring
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Global Warming Potential (GWP)
1) Production stage
8.76E-1
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
2) Use stage
ND
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
3) End of life stage
3.30E+0
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Eutrophication (EP)
1) Production stage
7.16E-04(freshwater) 9.67E-03 (marine) 9.84E-02 (terrestrial)
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
3) End of life stage
4.40E-08(freshwater) 6.31E-04 (marine) 7.26E-03 (terrestrial)
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Unit
kg P-Eq. [EP-freshwater]; kg N-Eq. [EP-marine]; mol N-Eq. [EP-terrestrial]
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Acidification potential (AP)
1) Production stage
2.53E-2
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
2) Use stage
ND
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
3) End of life stage
1.31E-3
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
4) Benefits and loads beyond the system boundries
-1.33E-3
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Unit
mol H+- Equivalent
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
Ozone Depletion Potential (ODP)
1) Production stage
1.55E-6
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
2) Use stage
ND
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
3) End of life stage
2,62E-16
Source
EPD, Reaction to Fire test report
Quality
[Externally audited industry specification]
ECO1.1 Life cycle costs
ECO1.1 Life cycle costs
Actual useful life
8 years
Source
FeRFA Guide to Specification and Application of Synthetic Resin Flooring
Quality
[Externally audited industry specification]
SOC1.2 Indoor air quality
SOC1.2 Indoor air quality
Indoor hygiene - volatile organic compounds VOCs
Formaldehyde concentration
<3 µg/m³
Source
Flowshield Acoustics Indoor Air Comfort Test Report (EUROFINS)
Quality
[Externally audited specific manufacturer information]
Other emission tests / labels
As part of Indoor Air Comfort - Belgian regulation, French VOC label, A class (or better) German regulation, AgBB and ABG requirements Italian CAM EU Taxonomy regulation
Source
Flowshield Acoustics Indoor Air Comfort Test Report (EUROFINS)
Quality
[Externally audited specific manufacturer information]
TVOC value
280 µg/m³
Source
Flowshield Acoustics Indoor Air Comfort Test Report (EUROFINS)
Quality
[Externally audited specific manufacturer information]
SOC1.3 Acoustic comfort
SOC1.3 Acoustic comfort
Rated building sound insulation value R`w
0 (no contribution) dB
Source
Flowshield Acoustics sound insulation test report (RISE AB)
Quality
[Externally audited specific manufacturer information]

Documents

Downloads

FC_SBU_Flowshield Acoustics_INT_20230103.pdf

pdf
253 KB

Manufacturer note

LCA Values for multi-layer product.

As the finished flooring system submitted is a multi-component, multi-layer composition, LCA values were taken from worst-case scenario and main GWP contributor level (bodycoat, membrane).



Note, updated values 31.01.2024 due to incorrect EPD reading previously.

Contact the manufacturer

Tremco CPG Germany GmbH

Tremco CPG Germany GmbH

Werner-Haepp-Str. 1
92439 Bodenwöhr
