Parador GmbH Parador GmbH

Designboden Modular ONE

Registration Code: 1G6LJM

Quality phase
ENV1.2 Version 2023 Risiken für die lokale Umwelt
QS 4
Holz und Holzwerkstoffe (u. nachw. Rohstoffe)

Product description

Modular ONE is the latest of our design floors and combines the best properties of resilient floor coverings and wood. As a design floor, Modular ONE is hard-wearing, suitable for damp rooms and easy to install thanks to its click technology.

What makes the floor special, however, is that it can hardly be distinguished from conventional real wood due to its extremely authentic feel and look and therefore offers a high level of walking and living comfort. In addition, all Modular ONE floors are certified with the Blue Angel. Conventional vinyl flooring or PVC flooring sometimes contains additives that can be harmful to human health - Modular ONE is completely free of these. Completely plasticiser-free and healthy for living.

Instructions for use

Design floorings are suitable for private and commercial use indoors. They are either installed floating on screed or other existing subfloors in conjunction with suitable underlays (insulating underlays) or glued to the full surface of the screed. The principles of proper installation can be found in the enclosed installation instructions or in the "Guide Design flooring Vinyl flooring and Modular ONE".

Reference to the DGNB system

ENV1.1 Building life cycle assessment
ENV1.1 Building life cycle assessment
Photochemical ozone creation potential (POCP)
1) Production stage
1.43E-2
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
2) Use stage
module not declared
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
3) End of life stage
6.36E-3
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-3.29E-3
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Unit
kg NMVOC-Equivalent
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Total use of non-renewable primary energy (PENRT)
1) Production stage
9.85E+1 MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
2) Use stage
module not declared MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
3) End of life stage
3.31E+0 MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-5.47E+1 MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Total use of renewable primary energy (PERT)
1) Production stage
1.43E+2 MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
2) Use stage
module not declared MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
3) End of life stage
5.40E-1 MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-1.23E+1 MJ
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
General life cycle assessment data
Building material class
Cfl - s1
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Reference Unit
1m²
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
If necessary, conversion of the reference unit
not required
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
End of life cycle
In case of selective dismantling, the product can easily be reused even after the end of the useful life. Residues and wastes from modular flooring must be recycled in accordance with AVV 17 02 01 and AVV 20 01 38. If repeated use of the product as floor covering is no longer possible, then the high heating value of approx. 17 MJ/kg means that it can be thermally recycled to generate process heat and electricity. Open burning or burning in a chimney is not possible as the combustion of treated wood and plastics results in harmful emissions. Incineration should therefore take place in a plant with a connected flue gas cleaning system, such as a waste incineration plant. According to AltholzV, AVV 17 02 01 and 20 01 38, placing old wood in a landfill is prohibited. Old wood category A II applies: glued, painted, coated, varnished, or otherwise treated old wood without organohalogen compounds in the coating and without wood preservatives.
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Useful life
20 years
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Global Warming Potential (GWP)
1) Production stage
-4.40E+0
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
2) Use stage
module not declared
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
3) End of life stage
9.78E+0
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-3.16E+0
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Unit
kg CO2-Equivalent
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Eutrophication (EP)
1) Production stage
3.09E-5
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
2) Use stage
module not declared
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
3) End of life stage
2.64E-7
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-4.11E-6
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Unit
kg P-Eq. [EP-freshwater]; kg N-Eq. [EP-marine]; mol N-Eq. [EP-terrestrial]
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Acidification potential (AP)
1) Production stage
1.54E-2
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
2) Use stage
module not declared
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
3) End of life stage
5.27E-3
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-4.11E-3
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Unit
mol H+- Equivalent
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Ozone Depletion Potential (ODP)
1) Production stage
6.75E-10
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
2) Use stage
module not declared
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
3) End of life stage
3.88E-11
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-3.59E-14
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
Unit
kg CFC11-Equivalent
Source
EPD-PAR-20210151-IBC1-DE
Quality
[Externally audited specific manufacturer information]
ENV2.2 Potable water demand and waste water volume
ENV2.2 Potable water demand and waste water volume
Installation-specific connected load
Flow rate (for sanitary fittings)
not relevant l/sec
Source
-
Quality
[Unaudited manufacturer specification]
Average flushing volume (of the sanitary equipment)
not relevant l/flush
Source
-
Quality
[Unaudited manufacturer specification]
ECO1.1 Life cycle costs
ECO1.1 Life cycle costs
Actual useful life
20 years
Source
not relevant
Quality
[Externally audited specific manufacturer information]
PRO1.4 Ensuring sustainability aspects in tendering and contracting
PRO1.4 Ensuring sustainability aspects in tendering and contracting
Tender textes
Suitable tender texts are currently only available in German. You can find them in our German download area under the heading "Ausschreibungstexte“.
Source
Manufacturer
Quality
[Unaudited manufacturer specification]
PRO2.5 Preparation of sustainable use
PRO2.5 Preparation of sustainable use
Maintenance, inspection, operating and care instructions
Information on cleaning and care can be found in the product guide on pages 24 and 25. This can be found at „https://parador.de/en/services/downloads/design-flooring“ under „Guides“
Source
Manufacturer
Quality
[Unaudited manufacturer specification]
SOC1.2 Indoor air quality
SOC1.2 Indoor air quality
Indoor hygiene - volatile organic compounds VOCs
Formaldehyde concentration
< 10 µg/m³
Source
FloorScore® SCS-FS-05098
Quality
[Externally audited specific manufacturer information]
Other emission tests / labels
Blue Angel; Floorscore; A+ émissions dans l'air intérieur
Source
Test certificates
Quality
[Externally audited specific manufacturer information]
TVOC value
≤ 300 µg/m³
Source
Blue Angel DE-UZ 176
Quality
[Externally audited specific manufacturer information]
Approval test according to AgBB scheme is available
Source
AgBB
Quality
[Externally audited industry specification]
SOC1.3 Acoustic comfort
SOC1.3 Acoustic comfort
Rated building sound insulation value R`w
not relevant dB
Source
-
Quality
[Unaudited manufacturer specification]
SOC1.4 Visual comfort
SOC1.4 Visual comfort
Visual contact with the outside
Class of the sun/glare protection with regard to visual contact to the outside
Source
-
Quality
[Unaudited manufacturer specification]
Colour rendering
Color rendering index Ra of artificial lighting
not relevant
Source
-
Quality
[Unaudited manufacturer specification]
TEC1.3 Quality of the building envelope
TEC1.3 Quality of the building envelope
Class of air permeability (joint permeability)
not relevant
Source
-
Quality
[Unaudited manufacturer specification]
Heat transfer coefficient U
13.33 W/(m²K)
Source
TDS (according to DIN EN 12667)
Quality
[Unaudited manufacturer specification]

Documents

Downloads

Ausschreibungstext

pdf
1 MB

Blauer Engel

pdf
230 KB

Katalog

pdf
7 MB

Floorscore

pdf
371 KB

PEFC.pdf

pdf
451 KB

TÜV-Zertifikat_2021-09-14

pdf
195 KB

HPD

pdf
137 KB

EPD

pdf
2 MB

Leistungserklärung_2023-07-01

pdf
208 KB

Technisches Datenblatt

pdf
155 KB

Ratgeber_Designboden

pdf
5 MB

FSC-Zertifikat.pdf

pdf
365 KB
