Sonae Arauco Deutschland GmbH

Innovus Decorative Panels Medium Density Fibreboard

Registration Code: HG889X

Labels recognized by DGNB FSC MIX FSC 100% PEFC
Holz und Holzwerkstoffe (u. nachw. Rohstoffe)

Product description

Medium density fibreboard (MDF) is a panel-­shaped wood-based material in accordance with EN 316 that is manufactured
in a dry process by means of compression under heat of wood fibres with adhesive. Coated MDF boards can be profiled. MDF can be coated with melamine facing according to EN 14322.
Due to their various densities and adhesive systems, they can display a variety of material properties and qualities like moisture resistance, fire retardant, load­bearing or others.
The area of application for uncoated MDF primarily involves decorative interior furnishings and furniture construction but also interior construction such as trade fair stands and shop design.
When painted or coated, MDF can also be found in kitchens, offices, bedrooms and living rooms.

Instructions for use

The components making up coated MDF correspond with the base material compositions as outlined in Clause 2.6. During hot pressing, the binding agent is linked irreversibly by means of poly­condensation and firmly bonded with the wood. The binding agents are chemically and stably bound to the wood.

VOC emissions: Sonae Arauco coated MDF is labelled as class A+ according to the French regulation on the labelling of emissions of volatile pollutants from construction and decoration products (with reference to the wall scenario, as a worst case).
Sonae Arauco MDF, coated with melamine impregnated paper at an average area weight of 13.3 kg/m2 stores 19.5 kg CO2 equivalent over its service life.

Environmental protection: According to current information, water, air and soil are not exposed to any dangers when the respective products outlined above are used as designated.

Health protection: According to current information, no damage to or impairment of health can be anticipated when MDF is used as designated.
With the exception of low volumes of formaldehyde for UF/MUF­ bonded MDF, VOC emissions from products are negligible, and are natural wood ingredients.

Reference to the DGNB system

ENV1.1 Building life cycle assessment
ENV1.1 Building life cycle assessment
Photochemical ozone creation potential (POCP)
1) Production stage
7.27E­02
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Modul nicht deklarier
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
2.88E­04
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
­-7.63E­03
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg NMVOC-Equivalent
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Total use of non-renewable primary energy (PENRT)
1) Production stage
2.09E+02 MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Modul nicht deklarier MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
­-3.78E+01 MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-2.47E+02 MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Total use of renewable primary energy (PERT)
1) Production stage
2.6E+02 MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Modul nicht deklarier MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
­-2.03E+02 MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
­-8.23E+00 MJ
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
General life cycle assessment data
Building material class
D-s2,d0 (EN 13986) ; B-s1,d0 (MDF Fire X)
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Reference Unit
m2
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
End of life cycle
Recycling: Sonae Arauco coated MDF from construction can be collected separately and utilised in the manufacture of MDF or other types of wood­based boards. This is based on the condition that the wooden boards are not fully glued. Energy recovery: Due to the high heating value of approx. 16.2 MJ/kg at 20 % moisture content assumed for post-consumer boards, coated MDF can be used for energy recovery and the generation of heat and electricity (e.g. in CHP plants), following the cascading principle for wood. Disposal Sonae Arauco coated MDF leftovers and residual materials incurred as a result of demolition measures on the building sites should be primarily directed towards material recycling. If this is not possible, they must be directed toward energy recovery instead of landfilling.
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Useful life
Due to the wide range of applications of Sonae Arauco coated MDF, no reference service life is declared.
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Global Warming Potential (GWP)
1) Production stage
-4.73+00
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Modul nicht deklarier
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
1.66E+01
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-­9.74E+00
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg CO2-Equivalent
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Eutrophication (EP)
1) Production stage
4.94E­-04; 1.41E­-02; 1.88E-­01
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Modul nicht deklarier
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
1.28E-05; 8.94E-­05; 1.02E-­03
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-­2.28E­-04; -1.6E-03; -­1.77E­-02
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg P-Eq. [EP-freshwater]; kg N-Eq. [EP-marine]; mol N-Eq. [EP-terrestrial]
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Acidification potential (AP)
1) Production stage
7.85E­-02
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Modul nicht deklarier
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
6.59E-­04
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-1.47E­-02
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Unit
mol H+- Equivalent
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Ozone Depletion Potential (ODP)
1) Production stage
1.4E­-06
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
2) Use stage
Modul nicht deklarier
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
3) End of life stage
6.2E­-09
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
4) Benefits and loads beyond the system boundries
-­1.88E­-06
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
Unit
kg CFC11-Equivalent
Source
EPD-SON-20230515-IBA1-EN
Quality
[Externally audited specific manufacturer information]
ECO1.1 Life cycle costs
ECO1.1 Life cycle costs
Actual useful life
Due to the wide range of applications of Sonae Arauco coated MDF, no reference service life is declared.
Source
EPD
Quality
[Externally audited specific manufacturer information]
PRO1.4 Ensuring sustainability aspects in tendering and contracting
PRO1.4 Ensuring sustainability aspects in tendering and contracting
Tender textes
Product description/Product definition: Medium density fibreboard (MDF) is a panel-­shaped wood-based material in accordance with EN 316 that is manufactured in a dry process by means of compression under heat of wood fibres with adhesive. Coated MDF boards can be profiled. MDF can be coated with melamine facing according to EN 14322. Due to their various densities and adhesive systems, they can display a variety of material properties and qualities like moisture resistance, fire retardant, load­bearing or others.
Source
EPD
Quality
[Externally audited specific manufacturer information]
PRO2.5 Preparation of sustainable use
PRO2.5 Preparation of sustainable use
Maintenance, inspection, operating and care instructions
Health protection: Due to the manufacturing conditions, no special health protection measures over and beyond the regulatory guidelines are required. The reference occupational exposure limit values are complied with. Emissions into air: Waste air generated during production is cleaned in accordance with regulatory requirements. Emissions have to comply with the values specified by the operation licenses of the different sites, specified according to national laws. Emissions into water/soil: No normal process contamination of water or soil exists. Waste water generated in the process is treated onsite and/or directed into the municipal sewage system following pre­treatment. Sludges generated within the water treatment can be used in agriculture as a fertiliser. Noise: Noise surveys are required and are performed for each site according to respective national regulations. Noiseintensive plant areas such as chipping are encapsulated or protected appropriately by structural measures. Whenever necessary (close to non­encapsulated areas), the use of ear protection is required (PPE, Personal Protective Equipment) within Sonae Arauco sites, as an additional safety measure.
Source
EPD
Quality
[Externally audited specific manufacturer information]

Documents

Downloads

ENV1.2 VOC_NAF certificate.pdf

pdf
1 MB

ENV1.2-TDS_INNOVUS DP MDF ST_DE.pdf

pdf
301 KB

ENV1.2-TDS_INNOVUS DP MDF FIRE X ECOBOARD_DE.pdf

pdf
303 KB

ENV1.2-2023- Reach Declaration_Sonae Arauco Deutschland_Feb2024.pdf

pdf
218 KB

ENV1.2-DoP_INNOVUS DP MDF Fire X ECOBOARD.pdf

pdf
286 KB

ENV1.2-EPD_ DP MDF_Val2029.pdf

pdf
2 MB

Manufacturer note

Innovus DP MDF

Innovus®Decorative Panels Medium Density Fibreboard are an engineered wood product that combines medium density fibreboard—a composite wood material made from wood fibres bonded with resin—with an impregnated decorative layer of paper. The impregnated decorative paper layer is thermally fused to the medium density fibreboard under pressure, creating a durable and versatile material with a smooth and aesthetically pleasing surface.

Innovus®Decorative Panels Medium Density Fibreboard are a sustainable, versatile, and cost-effective material that offers durability, aesthetic flexibility, and ease of maintenance, making it a perfect choice for a wide range of applications in both residential and commercial.

Contact the manufacturer

Sonae Arauco Deutschland GmbH

Sonae Arauco Deutschland GmbH

Grecostraße 1
49716 Meppen
